    Sugar Plant Small Coal Steam Boilers DZL Series Large Furnace Design Evenly Burned


    DZL Series Coal Fired Steam Boiler For Sugar Plant


    Product introduction


    • Horizontal structure, strong adaptability to coal types.

    • The outside of the boiler main unit is a three-dimensional guard shell, which adopts a water circulation system with natural circulation and ejector.

    • With the operation of the grate, the slag falls into the slag bucket and is discharged through the slag remover.

    • The flue gas generated by the combustion is mainly discharged from the induced draft fan to the chimney.

    • Built-in radiation heating surface and convection heating surface, heat transfer is sufficient.


    Parameter


    TypeDZL1DZL2DZL3DZL4DZL6DZL8DZL10
    ProjectUnit
    The enaporationT/h12346810
    The rated steam pressureMpa0.7,1.0,1.25,1.6,2.5
    The rated steam temperature170,184,194,203,226
    Feed temperature20,60,105
    Avaible fuelⅡ(AⅡ)
    Design the thermal efficiency80.280.180.380.680.380.580.6
    The fuel consumptionKg/h181378.4493723108915091750
    The transport dimension
    L*W*H(mm)
    mm5200*2100*30005525*2440*34006300*2650*34006081*2575*34008000*2900*35507526*3340*43008980*3200*3550


    Advantage


    1 . The boiler is equipped with an induced draft fan, a dust remover and a slag remover


    2 . Two-wing flue setting to avoid tube plate cracks


    3 . Large furnace design


    4 . The convection pipe is threaded


    5 . Enhance heat transfer and reduce heat loss


    6 . Coal is evenly burned


    7 . Minimize energy consumption
